DFD 5.15.1 Provide Detection for the Vehicle Surroundings

Overview

This High-level Function provides facilities for the detection of what is happening in vicinity of the Host Vehicle.  It contains functionality that can detect Other Vehicles, Other Road Users, Pedestrians, atmospheric conditions, visibility, road surface state and stationary objects.  The data produced by the detection functionality is sent to other functionality for storage and analysis.

Diagrams

The Diagram(s) is(are) the Diagram(s) where you can find the function
The first diagram, if exists, is a DFD diagram which provides the context of the function The second Diagram, if exists, is a Functional Tree which provides a hierarchical description of the function into subfunctions	DFD 5.15 Provide In-vehicle Detection Functional Tree of Area 5

Parent

5. Provide Support for Host Vehicle Services::5.15 Provide In-vehicle Detection and Analysis

Component lower level functions

5.15.1.1 Detect Other Vehicles near to Host Vehicle

5.15.1.2 Detect Other Road Users in nearby geographic area

5.15.1.3 Detect Pedestrians near to Host Vehicle

5.15.1.4 Detect Atmospheric Conditions near Host Vehicle

5.15.1.5 Detect Visibility in Host Vehicle vicinity

5.15.1.6 Detect Road Surface State in Host Vehicle vicinity

5.15.1.7 Detect Stationary Objects in Host Vehicle vicinity

5.15.1.8 Detect Vehicle Attitude Status

Input logical dataflows

fae-local_vehicle_conditions

frp-local_vehicle_road_surface_conditions

ft.p-presence_indication

fve.onv-vehicle_presence_indication

fve.oru-presence_indication

fve.so-object_presence_indication

Output logical dataflows

pshvs_data_for_incorrect_vehicle_attitude_warnings

pshvs_local_vehicle_atmospheric_data

pshvs_local_vehicle_road_surface_conditions

pshvs_local_vehicle_stationary_objects

pshvs_local_vehicle_visibility_data

pshvs_other_road_users_nearby

pshvs_pedestrians_detected_nearby

pshvs_vehicle_detected_nearby
